HydroChef-S
COMING SOON
Welcome to the future of cutting technology.
Our advanced 5-Axis machine transforms every cut into a masterpiece of engineering. Designed with industry-first innovations, it offers unparalleled accuracy across metals, composites, and ceramics.
Every element—from our revolutionary nozzle design that achieves a pristine, pipe-free aesthetic, to the seamlessly integrated camera and probing systems—has been engineered to exceed the demands of modern fabrication.
With dynamic 5-axis control, even the most intricate cuts become effortless. The machine’s clean lines, intuitive controls, and precision components forge a solution where form and function converge.
Experience a new era of performance, where each detail is crafted to deliver consistent, award-winning results.
Technical Specifications
| Model | Models available | X-axis travel (mm) | Y-axis travel (mm) | Z-axis travel (mm) | Max. speed (m/min) | Linear Accuracy (mm) | Repeatability (mm) | Pump/Unit/Spindle Motor | Footprint (m)* |
| 5-Axis | 4021-5AXG | 4100 | 2100 | 200 | 25 | +/- 0.02 | +/- 0.02 | Jekran Pump model 22/30 22/30kW - 3 phase - 3,800bar | 8.5x3.4 |
| 5-Axis | 6021-5AXG | 6100 | 2100 | 200 | 25 | +/- 0.02 | +/- 0.02 | Jekran Pump model 22/30 22/30kW - 3 phase - 3,800bar | 10.5x3.4 |
Pump Technical Specifications
| Model 22 Direct Drive | Model 30 Direct Drive | |
| Electric Servo Motor Power | 30 HP (22 kW) | 40 HP (30 kW) |
| Efficiency | ≥ 90% | ≥ 90% |
| Output Pressure PSI | 58,000 psi | 58,000 psi |
| Output Pressure Bar | 4000 Bar | 4000 Bar |
| Orifice & Flow Rate | 0.011" / 0.82 gpm (0.3 mm / 3.1 lpm) | 0.014" / 1.1 gpm (0.35 mm / 4.2 lpm) |
| Footprint LxWxH | 48" x 31" x 42"(1220 mm x 800 mm x 1065 mm) | 48" x 31" x 42"(1220 mm x 800 mm x 1065 mm) |
